Specifications

• CCD Resolution: 2048 pixels
• Supported CCD: ILX511, ILX554, ILX751
• Pixel size:
  • ILX511:     14µm x 200µm (14µm pitch)
  • ILX554:     14µm x 56µm (14µm pitch)
  • ILX751:     14µm × 14µm (14µm pitch)
• Programmable integration time: 1.8 ms to 10 min
• Wavelength range:
  • ILX511/ILX55/ILX7514: Visible CCD: 380nm – 980nm
  • ILX511/ILX554/ILX751 with UV coating: UV/VIS CCD: 200nm – 980nm ( Lumigan-coated )
• ADC resolution: 16 bits
• Connectivity: USB 2.0 (full speed)
• Programmable analog gain control: 1 to 6 V/V
• Programmable analog offset control: -300mV to +300mV
• Auxiliary data communication methods: I2C
• Five general purpose digital outputs
• Device usage time counter
• Powered by: USB or external 5V DC power supply

• DLL file for OEM design
